Gungarlin Diversion Weir - NSW

Weir spill

Tors in the sun

Sand trap outlet portal

Sand trap bulkhead gates

Behind the bars-intake interior

Exposed intake structure

The split tor

Rock bolt

Outlet gate passing 1 cumec flow

Gauge at 1213.1 m

Aqueduct air vent

Downstream face of weir

Aqueduct inlet behind trashrack

Water 0.8m below weir crest

Intake trashrack

Reservoir,Dam

Position

DEG: -36.275902 148.525299

DMS: 36º 16' 33.25" S 148º 31' 31.08" E

UTM: 55 H 5984370mN 636996mE

Altitude: 1233.29m

Address & Contact

Unnamed Road
Kosciuszko National Park NSW 2627

Phone: N/A

Email: N/A

Web: N/A

Information

Intercepts flow in Gungarlin River, diverting it into a 2.4m diameter and 1260 m long buried pipeline which is the aqueduct. Maximum discharge capacity is 14.7 cumecs. This empties into the Burrungubugge Intake where siphons transfer the water into the Eucumbene-Snowy tunnel.
A pleasant 4 km return bushwalk to the weir in a little visited part of Kosciuszko National Park. Park at the locked gate at turnoff to Island Bend Firetrail. Pass Burrungubugge Intake and walk on the access track with a gentle grade of 1 in 100, matching the hydraulic grade.
